    If we examine the vertical structure the atmosphere in different places we will find it varies in height, being lowest at the poles and highest at the equator. The varying height is due to the spatial variation in heating of the Earth's surface and thus the atmosphere above. This fact makes it difficult to define exact heights for the layers of the atmosphere. The solution is to subdivide the atmosphere not on the basis of fixed heights, but on temperature change. Figure \(\PageIndex{1}\) illustrates the way in which the atmosphere is divided using temperature change as the primary criterion.

    Troposphere and Tropopause

    The troposphere is the layer closest to the Earth's surface. The graph of temperature change indicates that air temperature decreases with an increase in altitude through this layer. Air temperature normally decreases with height above the surface because the primary source of heating for the air is the Earth. The rate of change in temperature with altitude is called the environmental lapse rate of temperature (ELR) The ELR varies from day-to-day at a place, and from place to place on any given day. The normal lapse rate of temperature is the average value of the ELR, 0.65o C /100 meters. That is, at any particular place and on any given day the actual ELR may be larger or smaller, but on average has a value of 0.65o C /100 m. So if I went outside today it could be 0.62o C /100 m and then tomorrow it might be 0.68o C /100 m. The ELR also varies from place to place on a given day. That is, at Chicago, Illinois it might be 0.65o C /100 m and on the same day it could be 0.62o C /100 m over London, England.

    Atmospheric temperature structure graph
    Figure \(\PageIndex{1}\): Structure of the Atmosphere

    Under the right conditions, the air temperature may actually increase with an increase in altitude above the Earth. When this occurs we are experiencing an inverted lapse rate of temperature, or simply an inversion. Shallow surface inversions are typical over the snow covered surfaces of subarctic and polar regions, and sometimes occur when high pressure cells inhabit a region.

    The tropopause lies above the troposphere. Here the temperature tends to stay the same with increasing height. The tropopause acts as a "lid" on the troposphere preventing air from rising upwards into the stratosphere.

    Stratosphere

    Above the tropopause lies the stratosphere. Note in Figure \(\PageIndex{1}\) that the temperature of the air does not change with an increase in elevation. If a layer of air exhibits no change in temperature with an increase in elevation we typically refer to it as an isothermal layer i.e. layer of equal temperature. Through most of the stratosphere the air temperature increases with an increase in elevation creating a temperature inversion. The inverted lapse rate of temperature is due to the presence of stratospheric ozone which is a good absorber of ultra-violet radiation emitted by the Sun. As energy penetrates downward, less and less is available for lower layers and hence the temperature decreases toward the bottom of the stratosphere. The downward reduction of heat transfer due to solar energy absorption from above is offset by the heat given off by the Earth creating the isothermal layer at the bottom of the stratosphere. At the top of the stratosphere lies the stratopause. Like the tropopause, the stratopause is an isothermal layer that separates the stratosphere from the mesosphere.

    Mesosphere and beyond

    It is the properties of the previously discussed layers that affects most of what we study in physical geography. Processes acting in layers above the stratopause have relatively little impact on our elemental study of Earth near-surface processes. In the mesosphere air temperatures begin to decrease with increasing altitude. 99.9 percent of the gases that comprise the atmosphere lie below this level. The air of the mesosphere is thus extremely thin and air pressure very small. With very few molecules like ozone capable of absorbing solar radiation, especially near the top of the layer, the air temperature decreases with height. The mesopause separates the mesosphere from the thermosphere above.

    Figure \(\PageIndex{1}\) shows air temperature increasing with increasing altitude in the thermosphere. Here, energetic oxygen molecules absorb incoming solar radiation raising the layer's temperature. Because solar activity determines the temperature of the layer, temperature at the top of the layer is warmer than that near the bottom of the thermosphere. Even though the temperatures are quite high in the thermosphere, the heat content of the layer is very low due the low density of air at this level.

    Polar mesospheric clouds
    Figure \(\PageIndex{2}\): Polar Mesospheric clouds. (Courtesy NASA EOS, Source)

    Polar mesospheric clouds are also known as noctilucent or "night-shining" clouds as they are usually seen at twilight. These clouds form at high latitudes and high altitudes (76 - 85 kilometers) near the boundary of the mesosphere and thermosphere.

    Functional layers

    Two layers, the ionosphere and ozonosphere are identified when using function as the criterion for subdivision. The ionosphere is not really a layer of the atmosphere, but an electrified field of ions and free electrons. The ionosphere absorbs cosmic rays, gamma rays, X-rays, and shorter wavelengths of ultraviolet radiation. The spectacular display of auroral lights is generally found in this region.

    The ozonosphere, also called the "ozone layer", is the concentrated layer of ozone found in the stratosphere. Ozone (O3) absorbs ultraviolet light between 0.1 - 0.3ตm. The ozone layer absorbs 97 - 99% of the Sun's ultraviolet light that can be harmful to life on earth. Though relatively constant through millions of years, seasonal fluctuations of ozone especially over the Arctic and Antarctic are common. The ozone layer is thinner at the equator and thicker at the poles. Ozone concentrations are highest in the spring and generally lowest during the autumn.

    Video: Reveal Earth's Atmosphere (Courtesy National Geographic)

    Assess your basic understanding of the preceding material by "Looking Back at Atmospheric Structure" or skip and continue reading.

    Looking Back at Atmospheric Structure \(\PageIndex{1}\)

    Explain what normally happens to air temperature as one moves upward through the troposphere.

    Answer

    Temperature decreases.

    Define the normal and environmental lapse rate of temperature.

    Answer

    The normal lapse rate of temperature is the average decrease in temperature with an increase in elevation. The environmental lapse rate is the decrease in temperature with an increase in elevation at any given time.

    What happens to air temperature as one moves upward through the stratosphere?

    Answer

    Generally increases.

    Define "temperature inversion".

    Answer

    A temperature inversion is a situation in which air temperature increases with increasing elevation.

    Describe the "functional layers" of the atmosphere and explain what do they do?

    Answer

    The ionosphere absorbs cosmic rays, gamma rays, X-rays, and shorter wavelengths of ultraviolet radiation. The ozonosphere absorbs 97% of the Sun's ultraviolet light that can be harmful to life on earth.
