Like other suburban areas, the surface geology of the Highland Park area was shaped by continental glaciers and their associated meltwater during previous glaciations (Figure \(\PageIndex{2}\)). However, the most recent glaciation that occurred some 15,000 years ago, commonly known as the Wisconsinan glaciation, is responsible for the majority of the sediments. In the Highland Park area, the accumulated glacial sediments are about 150 to 200 feet in thickness (Barnhardt, Surficial Geology of Highland Park Quadrangle, 2011). By contrast, the thickness of the Wisconsinan ice sheet at Chicago at the peak of the Wisconsinan glaciation is believed to have been 3,000 feet, twice the height of Willis (Sears) Tower Chicago (Chicago Tribune, The Massive Glacier That Formed the Great Lakes..., 2019).
Consider the relative thicknesses of the continental ice sheet and of the deposited glacial sediments as well as the thickest and thinnest values of the glacial sediments. Estimate what proportion of the ice sheet by volume was made up of rock particles in composition.
